MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip
MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip
MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip
MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip
MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip
MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip
MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip
MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip

MINI TS80 Digital OLED USB Type-C Programable Soldering Iron Station Solder Tool Built-in STM32 Chip

Regular price $62.00 Sale price $97.99 Unit price per
We keep deals after 11.11
DON'T miss it, lowest price and free delivery you both have.
-
TS80 is a smart soldering iron powered by USB Type-C interface and QC3.0 standard
Soldering more convenient. It can be powered by charging plug and power bank that meets the QC3.0 (9V 2A) standard.
The control shell of the soldering iron is integrally formed by aluminum alloy through CNC.
It is as mini as a pen, compact structure, ergonomic, beautiful and fashionable.

With OLED display, it can be easy to control the status of the soldering iron.
Built-in STM32 chip, can control the temperature rise and fall intelligently.
With sleep and automatic shutdown function.
Programable. You can develop the soldering iron firmware as needed.

Use an internal thermal ceramic heating core that transfers heat to the top of tip quickly through a pure copper thermal part.
Excellent temperature control performance.
The tips is connected to the control terminal via a 3.5mm plug, replacing the tip is faster and easier than ever.

Specification :

Temperature Range: 100℃ to 400℃ (Max)
Power Input: 3.6V-6.5V/3A, or 6.5V-9V/2A, or 9V-12V/1.5A ~ (QC 3.0)
Data/Power Interface: USB Type-C
Temperature stability: ±3%
Display: OLED
Control part: Length 95.5mm, Diameter: 13mm
Heating part: Length: 60+40mm, Diameter: 10.6mm

TS80 Controller Weight: 36.5g
Certifications: CE, FCC

Package includeds :

Standard Package:
1 x MINI TS80 Soldering Iron Controller
1 x TS-B02 Solering Iron Tip (New type of soldering tip, higher efficiency)

1 x English User Manual
1 x Color Retail Gift Box



More Accesseries Package:
1 x MINI TS80 Soldering Iron Station
1 x TS-D25 Solering Iron Tip
1 x Type-C Cable
1 x Power Plug Adapter
1 x Safety Ground Wire
1 x English User Manual
1 x
Allen Key
1 x Color Retail Gift Box



Share this Product
